Exporting CD Analyzer Files with the File Export Tool
Chromatic Dispersion Analyzer 71
Exporting Chromatic Dispersion Files
4. Select the files.
4a. Under Files To Be Exported, click Add.
A standard Open dialog box is displayed, allowing you to select
the desired files.
Note: You can speed up file selection by selecting several files at the same time.
4b. When you are done, in the dialog box, click Open to transfer the
files to the list.
Note: You can remove a specific file by selecting it and using Remove. If you want
to quickly empty the list, select Remove All.
5. Under Export Control, start the export process using the Export
File(s) button.
Successful export
Unsuccessful
export
