EXFO FTB-5800 Chromatic Dispersion Analyzer for FTB-500 User Manual
Page 17
Getting Started with Your Chromatic Dispersion Analyzer
Chromatic Dispersion Analyzer
11
Starting the Chromatic Dispersion Analyzer Application
The main window (shown below) contains all the commands required to
control the Chromatic Dispersion Analyzer:
Tabs
RGD
parameters
panel
Fiber
Information
panel
Intensity
meters
Status bar
Button bar
Source type
