Title bar – EXFO FTB-5700 Single Ended Dispersion Analyzer for FTB-500 User Manual
Page 19
Getting Started with the Single-Ended Dispersion Analyzer
Single-Ended Dispersion Analyzer
13
Starting the Single-Ended Dispersion Analyzer Application
The main window (shown below) contains all the commands required to
control the Single-Ended Dispersion Analyzer:
Title Bar
The title bar is located at the top of the main window. It displays the
module name and its position in the FTB-500. The module position is
identified as follows:
Slot number in which module is inserted
(0 identifies first slot)
Unit housing the module
(1 identifies FTB-500)
[ 1 – 1 ]
