Upgrading The Computer
Upgrading the Hard Disk Drive(s) 6 - 11
6
Removing the Hard Disk from the Secondary HDD Bay (Model C Only)
Note that the secondary hard disk (if installed) is located under the optical device
bay (CD/DVD).
1.
Turn the computer off, remove the AC/DC adapter, turn it over and remove the bat-
tery.
2.
Remove the optical device (see
“Upgrading the Optical Device (Model C)” on
)
3.
When the optical device is removed the secondary HDD assembly will be visible.
4.
Remove screws
-
from the secondary HDD assembly.
RAID Hard Disks
All hard disks in a RAID
should be identical (the
same size and brand) in
order to prevent unex-
pected system behavior.
Figure 6 - 8
Secondary HDD
Assembly Screws
1
3
3
1
2
