Eskape ™ 200 Hardwater Series (69161)
Page 12
GetEskimo.com
HIGH PERFORMANCE ICE FISHING GEAR
1-800-345-6007
®
PARTS lISTS
REf.
NO. DESCRIPTION PART NO. QTy.
1 BOLT, 1/4-20 X 3/4” HH gR5 8930 4
2 WASHER, 1/4” 48261 6
3 NUT, 1/4-20 HEX NYLOCK 67538 10
4 BOLT, 1/4-20 X 7/8” HHCS gR5 67541 6
5 POLE ASSEMBLY, SPREADER FEMALE (INCLUDES ONE .875” LARgE CLIP) 68046 2
6 POLE ASSEMBLY, SPREADER 36” (INCLUDES TWO .706” LARgE CLIPS) 68033 1
7 POLE ASSEMBLY, SPREADER 40.10” (INCLUDES ONE .706” LARgE CLIP & ONE .706” STUD) 68037 1
8 RISER, LEFT HINgE 68052 1
9 RISER, RIgHT HINgE 68053 1
10 POLE ASSEMBLY, SPREADER 34” (INCLUDES TWO .706” LARgE CLIPS) 68087 1
11 POLE, BOTTOM CROSS BRACE 68106 1
12 POLE, TOP CROSS BRACE 68117 2
13 HINgE ASSEMBLY, RIgHT 68143 1
14 HINgE ASSEMBLY, LEFT 68144 1
15 POLE ASSEMBLY, SPREADER MALE (INCLUDES ONE .706” LARgE CLIP) 68148 2
16 BOX, ROD HOLDER 68157 2
17 SEAT KIT (SEE PAgE 13 FOR PARTS) 69299 1
18 POLE, REAR CROSS BRACE 68352 1
19 SLED 68380 1
20 NUT, 1/4-20 TOP LOCK FLANgED BLK 48752B 10
21 BOLT 1/4-20 X 2-1/2” PHILLIPS TRUSS HD 67430 8
22 HINgE, DOUBLE SIDED HOLE 68050 2
23 POLE ASSEMBLY, J-POLE 68055 2
24 POLE ASSEMBLY, MIDDLE & FRONT UPRIgHT 68056 4
25 POLE ASSEMBLY, REAR UPRIgHT 68068 2
26 CAP, POCKET POLE 68060 8
27 CLIP, QRS POLE 68061 8
ITEmS BElOW NOT SHOWN
- CAP END, ROD HOLDER BOX 68156 2
- SCREW, 10-32 X 1/4” PAN HD 68136 8
- CLIP, LARgE .875” 68064 2
- CLIP, LARgE .706” 68063 7
- STUD, .706” 68309 1
- TOW ROPE 67589 1
- SCREW, #6 X 3/8” PHILLIPS TRUSS HD 69629 13
- SHELTER SKIN, RED 68019 1
- EDgE TRIM, 1/4” CUT TO 93.5” 69654 1
- WINDOW REPLACEMENT, 8” X 12” 69531 2
- WINDOW REPLACEMENT, 13.5” X 13.5” 69534 5
REPAIR PARTS
- PATCH KIT, RED 69742 -
