Eskape ™ 350 Hardwater Series (69163)
Page 1
GetEskimo.com
HIGH PERFORMANCE ICE FISHING GEAR
1-800-345-6007
®
PARTS lISTS
REf.
NO. DESCRIPTION PART NO. QTy.
1 BOLT, 1/4-20 X 3/4” HH gR5 8930 4
2 WASHER, 1/4” 48261B 6
3 SLED 67163 1
4 NUT, 1/4-20 HNyLk 67538 10
5 BOLT, 1/4-20 X 7/8 HHCS gR5 67541 6
6 POLE ASSEMBLy, SPREADER 46.60” (INCLUDES ONE .706” LARgE CLIP AND ONE .706”
STUD) 68041 1
7 POLE ASSEMBLy, SPREADER FEMALE 22.16” (INCLUDES ONE .875” LARgE CLIP) 68046 2
8 POLE ASSEMBLy, SPREADER MALE 50.59” (INCLUDES ONE .706” LARgE CLIPS) 68048 2
9 RISER, LEFT HINgE 68052 1
10 RISER, RIgHT HINgE 68053 1
11 POLE ASSEMBLy, SPREADER 34” (INCLUDES TWO .706” LARgE CLIPS) 68087 1
12 POLE ASSEMBLy, BOTTOM CROSS BRACE 68132 1
13 POLE ASSEMBLy, TOP CROSS BRACE 68133 3
14 HINgE ASSEMBLy, RIgHT 68139 1
15 HINgE ASSEMBLy, LEFT 68140 1
16 POLE ASSEMBLy, SPREADER 38.75” (INCLUDES TWO .706” LARgE CLIPS) 68151 1
17 BOX, ROD HOLDER 68160 1
18 SEAT kIT 69293 1
19 NUT, 1/4-20 TOP LOCk FLANgED BLk 48752B 10
20 BOLT 1/4-20 X 2-1/2” PHILLIPS TRUSS HD 67430 8
21 POLE ASSEMBLy, UPRIgHT 28.75” 68029 4
22 HINgE, DOUBLE SIDED HOLE 68050 2
23 POLE ASSEMBLy, J-POLE 32.5” 68057 2
24 CAP, POCkET POLE HINgE 68060 8
25 POLE ASSEMBLy, REAR UPRIgHT 27.25” 68069 2
ITEmS BElOW NOT SHOWN
- CAP END, ROD HOLDER BOX 68156 2
- SCREW, 10-32 X 1/4” PAN HD 68136 8
- CLIP, LARgE .875” 68064 2
- CLIP, LARgE .706” 68063 7
- STUD, .706” 68309 1
- TOW ROPE 67589 1
- SCREW, #6 X 3/8” PHILLIPS TRUSS HD 69629 13
- SHELTER SkIN, RED 68021 1
- EDgE TRIM, 5/16” CUT TO 114” 69529 1
- WINDOW REPLACEMENT, 8” X 12” 69531 2
- WINDOW REPLACEMENT, 13.5” X 13.5” 69534 5
REPAIR PARTS
- PATCH kIT, RED 69742 -
