ISA-40 Oxygen Monitor ENMET Corporation
15
6.0 ISA-40 Specifications 6.0 ISA-40 Specifications
Control Unit Specifications
Power 110 V AC (or 220 V AC if transformer standouts are reconfigured),
50/60 Hz, and/or 12 V DC , 20 watts max. (5 watts per channel)
Alarm Horn and red lamps on Control Unit.
Sensor Lifetime Approximately 14 months.
Warranted for 6 months from date of shipment.
Electronics Low power, all solid state, utilizing integrated circuits.
Dimensions 12" high x 8" wide x 7" deep
Weight 20 lbs.
Enclosure NEMA-4X Fiberglass
Oxygen Cell Specifications
Application General. Intermediate life and response time.
Response Time 90% in 15 seconds, at 25
°
C (typical)
Output Nominal (in air at 25
°
C) 175
±
5uA
At 0% Oxygen less than 2.0uA
Linearity error (0 – 100% Oxygen) less than 0.5%
Operating Temp. Range 32
°
F to 125
°
F
ENMET Warranty 6 months form shipment
Size 1.25
″
diameter by 0.80
″
long
Weight 26 grams
Expected Life Up to 14 months in air
N OTE : All specifications stated in this manual may change without notice.
7.0 Service Information 7.0 Service Information
7.1 Replacement Part Numbers
A full set of replacement part numbers and prices are a part of the documentation which accompanied the order. A
partial list of the most likely parts needed to maintain the equipment is as follows:
ENMET Part Number Description
67013-008 Oxygen Cell, S2, that has a gray label;
The P/N is for the packaged cell as furnished for a replacement
03296-209 Cylinder of 20.9% by volume oxygen in nitrogen
03296-170 Cylinder of 17% by volume oxygen in nitrogen
63001-002 14 V DC lamp
03600-002 Assembly, Calibrator
04537-000 Circuit board, one channel
04537-001 Circuit board, two channel
64002-050 Fuse, 0.05 Amp, 5x20 slow blow
66017-009 Sensor cable, specify length
64011-000 Intrinsic Safety Barrier
