Rear Panel & Functions
© 2010 EMM Labs Inc., All Rights Reserved. EMM Labs reserves the right to amend specifications & design without notice.
Rear Panel & Functions
5. Digital Outputs:
•
AES/EBU: AES/EBU (XLR) PCM digital audio output for Redbook CD and
MP3 CDs
•
DSD: EMM Labs OptiLink connector which enables the TSD1 to transfer
high resolution digital audio. via the included ST OptiLink fibre optic cable.
.
6. External Clock:
•
INT / EXT: When the switch is set to INT the TSD1 uses its internal clock.
On EXT the TSD1 locks to an external master clock input via the BNC
connector. (Refer to the Operations section for more details)
•
75Ω / HI Z: This toggle switch turns cable termination for the BNC clock
input on /off. In HI Z position it is turned off.
7. System:
Remote:
•
External IR: wired infra-red communication port
•
Wired RS232: RS232 communication port
Service:
•
USB: software update port please see Appendix A for details
•
RESET: Used to access the backup BIOS in connection with software
upgrades via the USB port. Should not be used during normal
operation. Please see Appendix A for details.
