Installation Instructions
Cabinet Installation
warninG
To avoid an explosion hazard, do not connect the cart or
appliance(s) to electrical power until after the gas supply
system has been checked for leaks.
iMPorTanT
To prevent damage to the gas regulator, install the
regulator only after the appliance is mounted in its
permanent position in the enclosure.
With at least one person on each side of the unit, lift it
up and lower it into the cabinet cut-out. As you lower it
into the cut-out slide the electrical cord into the utility
cut-out. •
Cart Installation
warninG
Attach the appliance to the cart with all of the
supplied bolts before use.
All gas and electrical connections should be made
after the grill is installed and bolted to the cart.
To avoid an explosion hazard, do not connect the
cart or appliance(s) to electrical power until after the
gas supply system has been checked for leaks.
•
•
•
iMPorTanT
To prevent damage to the gas regulator, install the
regulator only after the appliance is mounted in its
permanent position on the cart.
Remove the cart from the shipping pallet before
installation. The Dacor cart ships assembled ready for
installation of the outdoor grill. Set the cart in an open
location and lock the wheels on the cart to minimize
movement.
Remove the drawers.
With at least one person on each side, lift the appliance
up and lower it onto the cart. As you lower it onto the
cart slide the electrical cord into the utility cut-out.
Center the unit on the cart, making sure to line up the
threaded mounting holes under the bottom of the grill
with the holes in the top of the cart.
Thread all of the supplied bolts into the bottom of the
outdoor grill from inside the cart. Tighten the bolts into
place.
1.
2.
3.
4.
5.
oB36 or
oBs36
oBsB162
oB52 or
oBs52
Insert power cord
into utility cut-out
Insert power cord
into utility cut-out
utility cut-out
rotating wheel
locking
wheel
Tank
shelf
36-Inch cart Shown
locking
wheel
