Elenco Snap Circuits SOUND ® - Manual (Page 4)

-3-
Important: If any parts are missing or damaged, DO NOT RETURN TO RETAILER. Call toll-free (800) 533-2441 or e-mail us at:
[email protected]. Customer Service • 150 Carpenter Ave. • Wheeling, IL 60090 U.S.A.
Parts List (Colors and styles may vary) Symbols and Numbers (page 2)
Qty. ID Name Symbol Part # Qty. ID Name Symbol Part #
r
1 NPN Transistor 6SCQ2 r
1
Tube for Sound
Energy Demo
Container
6SCSEDCT
r 1 100 W Resistor 6SCR1 r 1
Flexible Sheet for Sound
Energy Demo Container
(may include spare)
6SCSEDCF
r 1 5.1k W Resistor 6SCR3 r 1 Speaker 6SCSP2
r 1 Adjustable Resistor 6SCRV r 1 Keyboard 6SCU26
r 1
500k W Adjustable
Resistor
6SCRV3 r 1 Voice Changer 6SCU27
r 1 Photoresistor 6SCRP r 1 Echo IC 6SCU28
r 2 Slide Switch 6SCS1 r 1 Microphone 6SCX1
r 1 Press Switch 6SCS2 r 1 Stereo Cable 9TLSCST
r 1
Base for Sound
Energy Demo
Container
6SCSEDCB
You may order additional / replacement parts at our website: www.snapcircuits.net
