Parts List (Colors and styles may vary) Symbols and Numbers (page 1)
Qty. ID Name Symbol Part # Qty. ID Name Symbol Part #
r 1
Base Grid
(11.0” x 7.7”)
6SCBG
r 1
0.1 m F Capacitor 6SCC2
r 3 1-Snap Wire 6SC01
r 1
470 m F Capacitor 6SCC5
r 7 2-Snap Wire 6SC02
r 1
1 m F Capacitor 6SCC7
r 3 3-Snap Wire 6SC03
r 1 Color Light Emitting
Diode (LED)
6SCD8
r 1 4-Snap Wire 6SC04
r 1
Egg LED Attachment 6SCEGG
r 1 5-Snap Wire 6SC05
r 1
Jumper Wire (black) 6SCJ1
r 1 6-Snap Wire 6SC06
r
1
Jumper Wire (red) 6SCJ2
r 2
Battery Holder - uses
two (2) 1.5V type “AA”
(not included)
6SCB1
r 1
Audio Jack 6SCJA
You may order additional / replacement parts at our website: www.snapcircuits.net
5
4
3
2
1
C2
C7
C5
6
B1 JA
D8
