Elenco Mini Electric Guitar - Manual (Page 4)

Notes for tightening screws
Full scale
of screwdriver
CAUTION! Please be sure to read the following instructions
before assembling this kit.
• Take necessary caution when handling parts with pointed edges. There is a risk of injury.
• This kit includes screws and other small parts. Be careful not to swallow them.
There is a risk of suffocation.
When tightening screws, firmly press the screwdriver
straight against the screw and turn. It is said that 70
percent of the force applied is used for pushing against the
screw and 30 percent for turning it. The types of screws
used are those that carve grooves into the plastic as they
are inserted (self-threading). For this reason, the screw
hole may be damaged if you exert too much force when
tightening the screw. Since it is difficult to turn a precision
screwdriver, please use a small driver that has a grip radius
of about 2 cm.
Part List
How to Assemble
Built-in Amp and Speaker
Mini Electric Guitar
Headstock
Body cover Body
Neck
Neck cover
Strings (4)
battery compartment cover
Circuit board
Speaker
Pickup top plate Magnet
Tuning peg knobs (4)
Volume dial Coil wire Sticker Pickup bottom
plate
Lead wires
Bolts/Nuts
(2 each)
Tuning peg
nuts (4)
String anchor
shaft
Bridges (4) Tuning shafts (4) Pick
Things you will need
Screwdriver; cellophane tape; rubber bands; scissors; two AA
alkaline batteries or two zinc-carbon batteries. (* NiCd and other
rechargeable batteries have low voltage. Therefore the guitar
may not work when these batteries are used. Oxyride batteries
have high voltage. Using these batteries may break the circuit.) Two AA batteries are used. Incorrect use of the batteries may cause the generation
of heat, explosions or liquid leakage. The following precautions should be taken.
• Do not use rechargeable batteries such as NiCd batteries, or Oxyride batteries
• Ensure that the positive and negative terminals of the batteries are aligned
correctly.
• If liquid that leaked from batteries gets into your eyes, rinse it well with plenty of
water and consult a doctor immediately. If liquid leaks onto your skin or clothes,
immediately wash it off.
• Always remove the batteries after use.
• Do not mix old and new batteries.
• Store the kit in a location out of the reach of small children.
* Please read the instructions and cautions thoroughly before use.
* For your safety, be sure to follow the instructions and cautions in this manual. In
addition, do not use any parts that have become damaged or deformed during use.
Washer head
screw (8)
Screw (large)
(1)
Screw (medium)
(5)
Screw (small)
(1)
4 JR.SCIENTIST
