Elenco Night’n Day® - Manual (Page 5)

7 8
6 - Before continuing, check the LED lamp. It is very bright. When it is on do
not look directly at it. Insert the AC adaptor plug into the jack in the
motor case and plug the power cord into an outlet. Push the square lamp
button on the base of the motor case. The lamp should come on. If it
doesn’t, push the button again. If the lamp still does not light, unplug
the cord, then push the lamp down into the socket – it might not be
making electrical contact. Plug the cord in again and push the button.
Push the button and turn off the lamp and unplug the globe.
7 - Attach the northern hemisphere
to the southern hemisphere.
The two halves fit together at
the equator around the Earth
globe. Make sure the continents
and lines of longitude line up.
7.2
7.1
7
8
8 - Connect the AC adaptor to the base and plug the cord into an outlet.
Turn the light on and you will see that half of the globe is lit. You will
not see the globe turning since it turns at the same rate as the real Earth.
If you put your ear close to the base you can hear the motor turning.
FOR USA/CANADA
INPUT: 120V AC 60Hz
OUTPUT: 7.5V DC 800mA
FOR UK
INPUT: 240V AC 50Hz
OUTPUT: 7.5V DC 800mA
FOR EUROPE
INPUT: 230V AC 50Hz
OUTPUT: 7.5V DC 800mA
FOR AUSTRALIA
INPUT: 240V AC 50Hz
OUTPUT: 6V DC 500mA
AC/DC Adaptor Specification
ETL LISTED
CONFORMS TO
UL STD. 697
CERTIFIED TO CSA
STD. C22.2 NO. 173 3165776
