Earth Auger Powerhead E43/E43CE
E43 ENGINE PartS LISt
kEY
NO.
Part NO. DESCrIPtION
qtY.
1
300484
FLYWHEEL, MAGNETO
1
2
300337
NUT, FLANGE M8
1
3
300462
WASHER, ROTOR
2
4
300413
CLUTCH ROTOR ASSEMBLY W/SPRING
1
5
300449
WASHER, SPRING
2
6
300450
BOLT, SHOULDER
2
7
300467
PIN, LOCATING
2
8
3004110
MOUNT RING & SHROUD
1
9
300491
RECOIL CLUTCH
1
10
300429
PLATE, RECOIL
1
11
3004121
HANDLE, RECOIL (STANDARD)
1
12
300430
RECOIL ASSEMBLY WITH STANDARD
HANDLE
1
13
300472
IGNITION COIL
1
13*
300472CE IGNITION COIL CE
1
14
300482
SHROUD, ENGINE
1
15
300493
BOLT, STUD M6 X 62MM
2
16
300475
GASKET, MUFFLER
1
17
4813
MUFFLER
1
18
4812
COVER, MUFFLER
1
19
BM6A
SPARK PLUG
1
20
300483
COVER, ENGINE SHROUD
1
21
300476
GASKET, INTAKE
1
22
300478
WINDPIPE, INTAKE 43CC/51CC
1
23
300479
GASKET, CARBURETOR
1
24
300486
CARBURETOR
1
25
300481
O-RING, CARBURETOR
1
26
3004109
PRIMER BULB
1
27
3004158
COVER, AIR FILTER
1
28
3004150
AIR FILTER ASSEMBLY
1
29
3004156
FOAM, AIR FILTER
1
30
3004157
PLATE, REINFORCEMENT
1
31
3004150
AIR FILTER ASSEMBLY
1
32
3004150
AIR FILTER ASSEMBLY
2
33
3004150
AIR FILTER ASSEMBLY
1
34
3004150
AIR FILTER ASSEMBLY
1
35
3004150
AIR FILTER ASSEMBLY
1
kEY
NO.
Part NO. DESCrIPtION
qtY.
36
56105
BRACKET, GAS TANK
1
37
3004118
GAS TANK KIT (INCLUDES TANK.
GROMMET, FUEL LINE, FUEL FILTER
AND GAS CAP.)
1
38
300401
GAS CAP, MANUAL VENTING
1
39
300332
SHROUD, GAS TANK
1
40
1021
SWITCH, ROCKER
1
41
3004105
KIT FUEL LINE TWO HOLE GROMMET
1
42
3004105
KIT FUEL LINE TWO HOLE GROMMET
1
43
3004105
KIT FUEL LINE TWO HOLE GROMMET
1
44
300335
BOLT W/WASHER PHILLIPS HH
4
45
300492
NUT, FLANGE M6
2
46
300471
BOLT W/WASHER M5 X 12MM
4
47
300439
BOLT W/WASHER PH M5 X 18MM
7
48
300336
BOLT HH M6 X 10MM
2
49
300438
BOLT W/WASHER M5 X 25MM
2
50
300456
BOLT M5 X 50MM
2
51
300338
KEY, FLYWHEEL
1
52
3004103
FILTER, FUEL
1
53
300351
BOLT HH M6 X 8MM
2
-
3004114
KIT, CARBURETOR
1
* For E43CE Only.
