Operator's Manual
Earth Auger Powerhead E43/E43CE
E43 POWErhEaD PartS LISt
kEY
NO.
Part
NO.
DESCrIPtION
qtY.
1
E43CCV
GAS ENGINE, 43CC
1
2
1027F
HANDLEBAR, FOAMED
1
3
3004119
TRANSMISSION COMPLETE
1
4
4809
TRIGGER ASSEMBLY
1
5
4814
BOLT 10-24 X 1-1/4 PHILLIPS TRUSS HD
1
6
4811
THROTTLE CABLE
1
7
8930B
BOLT 1/4-20 X 3/4 HH GR5 BLK
4
8
3004111
GEAR CASE TOP
1
9
3004100
CLUTCH DRUM
1
10
8922
BALL BEARING R12 DOUBLE LIP
3
11
9814
GEAR 7T PINION THREADED, 5/8”
THREAD
1
12
8924
SNAP RING
2
13
8915
DOWEL PIN STEEL 1/4” X 1/2”
1
14
8912
GEAR 44T 3/4” HOLE
1
15
8919
GASKET
1
16
8923
BALL BEARING R10
2
17
9214
GEAR 10T/48T ONE-PIECE CLUSTER
1
18
8939
GEAR CASE BOTTOM
1
19
8913
SHAFT OUTPUT 7/8”
1
20
8929
BOLT 1/4-20 X 1-1/2 SHCS
2
21
8931F
BOLT 1/4-20 X 2 SHCS F-T
4
22*
EA2F
EARTH AUGER 2”, COMPLETE
1
EA3F
EARTH AUGER 3”, COMPLETE
1
EA4F
EARTH AUGER 4”, COMPLETE
1
EA6F
EARTH AUGER 6”, COMPLETE
1
EA8F
EARTH AUGER 8”, COMPLETE
1
EA10F
EARTH AUGER 10”, COMPLETE
1
kEY
NO.
Part
NO.
DESCrIPtION
qtY.
23
1423
BOLT 5/16-18 X 2 HHCS GR5
2
24
WF516
WASHER, FLAT 5/16” STANDARD
2
25
60G56
NUT 5/16-18 BI-WAY LOCK
2
26
53684
SHOCK TOP 1-PC
1
27
8980
SHOCK SPRING
1
28** EB4
EARTH BLADE, 4”
1
EB6
EARTH BLADE, 6”
1
EB8
EARTH BLADE, 8”
1
EB10
EARTH BLADE, 10”
1
EB6HD
HEAVY DUTY EARTH BLADE, 6”
1
EB8HD
HEAVY DUTY EARTH BLADE, 8”
1
EB10HD
HEAVY DUTY EARTH BLADE, 10”
1
29
EBOLT
BOLT 1/4-28 X 5/8 HH GR5
2
30
ENUT
NUT 1/4-28 BI-WAY LOCK
2
31
8958HD
FISHTAIL POINT SHARPENED
1
8970
POINT, EARTH 2” & 3” AUGERS
1
32
1433
BOLT 3/8-16 X 1-1/2 HH
1
33
2104
NUT 3/8-16 HEX LOCK BI-WAY
1
-
EXT6
DEPTH EXTENSION 6”
1
EXT12
DEPTH EXTENSION 12”
1
EXT18
DEPTH EXTENSION 18”
1
* Includes blade, fishtail point, shock spring, shock top, & hardware.
** Includes mounting hardware.
auGEr PartS & aCCESSOrIES LISt
