background image

SMT Power Inductor

SI85 Type

Features

RoHS compliant.

mounting.

Low profile (5.5mm max. height) SMD type.
Unshielded.
Self-leads, suitable for high density
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Idel for power source circuits, DC-DC converter,DC-AC inverters
inductor applications.
In addition to the standard versions shown here, customized inductors
are available to meet your exact requirements.

DELTA ELECTRONICS, INC.

(TAOYUAN PLANT CPBG)

7

0.00

0.01

0.10

1.00

10.00

CURRENT (A)

1.00

10.00

100.00

1000.00

IN

D

U

C

T

A

N

C

E

(u

H

)

471

391
331

271

221
181
151
121

101
820
680
560
470
390
330

270
220
180
150
120
100

Electrical Characteristics:

252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com

SI85 - 0R8

0.8

0.0047

10.00

SI85 - 1R2

1.2

0.0061

8.00

SI85 - 2R2

2.2

0.0110

5.20

SI85 - 2R7

2.7

0.0150

4.60

SI85 - 4R7

4.7

0.0210

3.40

SI85 - 6R8

6.8

0.0400

2.80

SI85 - 100

10.0

0.0700

2.30

SI85 - 120

12.0

0.0800

2.00

SI85 - 150

15.0

0.0900

1.80

SI85 - 180

18.0

0.1000

1.60

SI85 - 220

22.0

0.1100

1.50

SI85 - 270

27.0

0.1200

1.40

SI85 - 330

33.0

0.1300

1.30

SI85 - 390

39.0

0.1600

1.20

SI85 - 470

47.0

0.1800

1.10

SI85 - 560

56.0

0.2400

0.94

SI85 - 680

68.0

0.2800

0.85

SI85 - 820

82.0

0.3700

0.78

SI85 - 101

100.0

0.4300

0.72

SI85 - 121

120.0

0.4700

0.66

SI85 - 151

150.0

0.6400

0.58

SI85 - 181

180.0

0.7100

0.51

SI85 - 221

220.0

0.9600

0.49

SI85 - 271

270.0

1.1100

0.42

SI85 - 331

330.0

1.2600

0.40

SI85 - 391

390.0

1.7700

0.36

SI85 - 471

470.0

1.9600

0.34

SI85 - 561

560.0

2.1600

0.31

SI85 - 102

1000.0

3.8500

0.26

25

100KHz, 0.1V for 0.8~6.8uH. 1KHz,1.0V for 10uH~1000uH.

o

C,

PART NO.

L

(uH)

1

DCR

( ) MAX

Irated

(Adc)

2

1. Tolerance of inductance : 15% for 0.8~6.8uH, 10% for 10~1000uH.
2. Irated is the DC current which cause the inductance drop less than 10% of its nominal inductance without current

o

and the surface temperature of the part increase less than 45 C.

o

o

3. Operating temperature: -20 C to 105 C (including self-temperature rise).

8.0

B

C

8.0

1.4

D

A

Mechanical Dimension:

UNIT:mm/inch
A = 7.8 0.2 / 0.307 0.008
B = 7.0 0.2 / 0.276 0.008
C = 5.0 0.5 / 0.197 0.020
D = 1.5 0.2 / 0.059 0.008

¡У

¡У

¡У

¡У

¡У

¡У

¡У

¡У

RECOMMENDED PAD PATTERNS
