30 A.LEDA WASH CC TW W
• FUNCTION
The functions are actived passing through the “unused range” and staying 5 seconds
in necessary level.
Last selected function still active. Enable setting a new function.
DIMMER CURVE 1 - GAMMA 1 LINEAR
DIMMER CURVE 2 - GAMMA 1,5
DIMMER CURVE 3 - GAMMA 2,0
DIMMER CURVE 4 - S
• RESET
BIT EFFECT
255
128
127
77
76
26
25
0
ZOOM RESET
UNUSED RANGE
Pan / Tilt reset is activated passing throug the unused range
and staying 5 seconds in Pan / Tilt reset levels
Effects reset is activated passing throug the unused range
and staying 5 seconds in Effects reset levels.
COMPLETE RESET
COMPLETE RESET
PAN / TILT RESET
PAN / TILT RESET
ZOOM RESET
Complete reset is activated passing throug the unused range
and staying 5 seconds in complete reset levels
• ZOOM
BIT EFFECT
255 WIDE BEAM
0 NARROW BEAM
K10 CC
K10 W
K10 TW
K20 CC
K20 W
K20 TW
K10 CC
K10 W
K10 TW
K20 CC
K20 W
K20 TW
K10 CC
K10 W
K10 TW
K20 CC
K20 W
K20 TW
