A.LEDA WASH CC TW W
1
2
3
4
1
3
2
4
10
11
Opening the covers - Fig. 10
Removing/Assembling the lens unit - Fig. 11
NB: Apply Loctite 222 (p/n COL002) to the threads of the 3 screws (1) before tightening them. A torque of 0.3N is recommended in order to avoid
damaging the zoom movement actuators.
MAINTENANCE
