32 A.LEDA WASH
A.LEDA WASH K20
CHAN-
NEL
EXTENDED RGBW
CHANNEL MODE
Red
Red fine
Green
Green fine
Blue
Blue fine
White
White fine
Linear CTO
Macro colour
Strobe
Dimmer
Dimmer Fine
Pan
Pan Fine
Tilt
Tilt Fine
Function
Reset
Zoom
Red LED 1
Green LED 1
Blue LED 1
White LED 1
Red LED …
Green LED …
Blue LED …
White LED …
Red LED 37
Green LED 37
Blue LED 37
White LED 37
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
…
…
…
…
165
166
167
168
CHAN-
NEL
EXTENDED
CHANNEL MODE
Red
Red fine
Green
Green fine
Blue
Blue fine
White
White fine
Linear CTO
Macro colour
Strobe
Dimmer
Dimmer Fine
Pan
Pan Fine
Tilt
Tilt Fine
Function
Reset
Zoom
Red LED 1
Green LED 1
Blue LED 1
Red LED …
Green LED …
Blue LED …
Red LED 37
Green LED 37
Blue LED 37
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
…
…
…
129
130
131
CHAN-
NEL
SHAPES
CHANNEL MODE
Red
Red fine
Green
Green fine
Blue
Blue fine
White
White fine
Linear CTO
Macro colour
Strobe
Dimmer
Dimmer Fine
Pan
Pan Fine
Tilt
Tilt Fine
Function
Reset
Zoom
Shape Selection
Shape Speed
Shape Fade
Shape R
Shape G
Shape B
Shape W
Shape Dimmer
Background Dimmer
Shape Transition
Shape Offset
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
CHAN-
NEL
STANDARD
CHANNEL MODE
Red
Red fine
Green
Green fine
Blue
Blue fine
White
White fine
Linear CTO
Macro colour
Strobe
Dimmer
Dimmer Fine
Pan
Pan Fine
Tilt
Tilt Fine
Function
Reset
Zoom
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
NB: To prevent accidental breakage of the effects,
which could collide with each other during transport,
before switching the projector OFF check that all the
projector Channels have been excluded (DMX level @0 bit).
