Multi-Appliance Comfort Control
Controls- Installation / Setup / Commissioning
SETTING UP THE CONTROLS – DUCTED EVAPORATIVE AIR CONDITIONING
S
ETTING M INIMUM F AN S PEED
1. Using the MANUAL/AUTO button set the unit to MANUAL
2. Using the HEAT/COOL/FRESH AIR button set the unit to
COOL FRESH AIR
3. Adjust the fan speed to the minimum fan speed level and
press ENTER.
4. Press the ENTER and ECONOMY/ BOOST buttons together
for approximately 10 seconds pressing the ENTER button first.
5. The words FAN SPEED and a number under the room
temperature will flash.
6. Adjust minimum fan speed to a number suitable to the system
design. Ensure that the motor does not over-temp if setting the
fan speed lower.
7. Press ENTER to keep new fan speed.
S
ETTING
M
AXIMUM
F
AN
S
PEED
Maximum fan speed can only be access after the minimum fan
speed has been checked.
1. Using the MANUAL/AUTO button set the unit to MANUAL.
2. Using the HEAT/COOL/FRESH AIR button set the unit to
COOL FRESH AIR.
3. Using the ECONOMY/BOOST button set the unit to BOOST.
Press ENTER.
4. Press the ENTER and ECONOMY/ BOOST buttons together
for approximately 10 seconds pressing the ENTER button first.
5. The words FAN SPEED and a number under the room
temperature will flash.
6. Adjust maximum fan speed to 35 or a number to suit the
system design.
7. Press ENTER to keep new fan speed.
Setting the fan speeds to a low setting should be completed by an
authorised installer / service technician. Motor warranty may be
voided for incorrect settings.
