GOT815-834 User ’s Manual
System Configurations 9
2.2 Water-proof Cables
GOT-800 series uses specific M12 connector for water-proof. Therefore you will
order each cable base on application.
There are four kind cables of GOT815, by the optional, if you will apply the USB,
COM or Etherent then you can select a cable for the package .
The Power cable included in the accessory box, when you will need the power
adapter, also it can be sesected by optional.
2.2.1 Power cable
Please follow pin assignement for the power input.
Pin Signal
V+
DC 9~36V power input
Earth Ground
GND
GND
GND GND
