ICO300 Series U

ser’s Manual

Hardware Installation

Step 1 Turn off the system.

Step 2 Loosen all screws of the cover

and remove the cover from the system.

Step 3

Stick CF mylar on CF card.

Step 4

Insert the CF card into the socket tightly.

Note:

Pullout the CF card from the socket when taking out.
