Dynaudio SERIES 2 ESOTEC - Manual (Page 5)

Esotec / Esotar 2 Series 5
Technical specifications
Tweeters/Midrange
Woofers
MD 102 MD 142 Esotar 2 110
Nominal impedance 8 Ω 8 Ω 6 Ω
Recommended frequency range 2200 – 30000 Hz 700 – 6000 Hz 2000 – 30000 Hz
Power handling
• Nominal long term IEC
• Transient
100 W
500 W 100 W
1000 W
150 W
1000 W
Net weight 0.126 kg 0.75 kg 0.50 kg
Overall dimensions (Ø x D) 62.2 x 43 mm 121 x 66 mm 111 x 41 mm
MW 152 MW 162 MW 162 GT MW 172 MW 182 Esotar 2 650 Esotar 2 1200
Nominal impedance 4 Ω 4 Ω 4 Ω 4 Ω 4 Ω 4 Ω 4 Ω
Recommended frequency
range 55 – 3500 Hz 40 – 4000 Hz 40 – 4000 Hz 35 – 3500 Hz 30 – 2000 Hz 50 – 4000 Hz 18 – 300 Hz
Power handling
• Nominal long term IEC
• Transient
100 W
1000 W
120 W
1000 W
120 W
1000 W
150 W
1000 W
180 W
1000 W
200 W
1000 W
400 W
1500 W
Net weight 1.1 kg 1.2 kg 1.1 kg 1.3 kg 1.85 kg 1.25 kg 8.8 kg
Overall dimensions (Ø x D) 146 x 70 mm 175 x 77 mm 166 x 71 mm 200 x 88 mm 239 x 86 mm 169 x 78 mm 297 x 162 mm
