Connecting the Esotec crossovers
Esotec / Esotar 2 Series 15
1. To connect the woofer
X Connect terminal 1 to the – terminal of the woofer.
X Connect terminal 2 to the + terminal of the woofer.
2. To connect the tweeter
The terminals 4, 5 and 6 offer the ability to fine-tune the sound level. This makes it possible to adjust the level
according to the placement of the speaker in the car and to your personal preference.
X Connect terminal 3 to the – terminal of the tweeter.
X Connect terminal 4 or 5 or 6 to the + terminal of the tweeter.
– just use one of the terminals 4, 5 or 6
– start with terminal 5 for the first setup
– use terminal 4 to
increase the sound pressure level by 2 dB
– use terminal 6 to decrease the sound pressure level by 2 dB
3. To connect the midrange
The terminals 8, 9 and 10 offer the ability to fine-tune the sound level. This makes it possible to adjust the level
according to the placement of the speaker in the car and to your personal preference.
X Connect terminal 7 to the – terminal of the midrange.
X Connect terminal 8 or 9 or 10 to the + terminal of the midrange.
– just use one of the terminals 8, 9 or 10
– start with terminal 9 for the first setup
– use terminal 8 to
increase the sound pressure level by 2 dB
– use terminal 10 to decrease the sound pressure level by 2 dB
4. To connect the power amplifier
X Connect terminal 2 to the + terminal of the power amplifier.
X Connect terminal 3 to the – terminal of the power amplifier.
