LPC-1009/1209/1509/1709/1909 Series
8 LPC-1009/1209/1509/1709/1909 Series Quick Reference Guide
Panel
Model LPC-1509 LPC-1709 LPC-1909
LCD size 15", 4:3 17", 4:3 19", 4:3
Display type XGA SXGA
Resolution 1024 x 768 1280 x 1024
Pixel pitch 0.297mm(H) x 0.297mm(V) 0.264mm(H) x 0.264mm(V) 0.294mm (H) x 0.294mm (V)
Luminance 400 cd/m² 350 cd/m²
Contrast ratio 700 800 1000
Viewing angle 70(U), 70(D), 80(L), 80(R ) 80(U), 80(D), 85(L), 85(R )
Response time 16 ms 30 ms 10ms
Backlight LED
Touch type 5 Wires resistive
Touch Light
transmission
80
Touch
interface
USB (EETI)
System
Board EBM-BYT
CPU Onboard Intel® Atom Quad-Core E3845 1.91GHz with Integrated Chipset
I/O Chipset E/C IT8528E
System
Memory
One 204-pin DDR3L SODIMM Socket Supports Up to 8GB DDR3L 1333 SDRAM
SSD One CompactFlash Type I/ II Socket (Support optional InnoDisk CF-SATA)
Hard Driver
Bay
One 2.5" SATA HDD
Watchdog
Timer
H/W Reset, 1sec. ~ 65535sec./1sec.step
H/W Status
Monitor
Monitoring system temperature, voltage, and cooling fan status. Auto throttling control
when CPU overheats
Expansion 1 x mPCIe with SIM Slot, 1 x mPCIe Supports mSATA
Rear I/O
Serial Port 1 x RS-232 1 x RS-232, 1 x RS-485
Ethernet 2 x RJ-45
HDMI 1 x HDMI
Audio Port 1 x Line-out
USB 1 x USB 3.0, 1 x USB 2.0 (Optional Extra 2 x USB 2.0)
Speaker 2 x 1W
Display
Chipset Intel Bay Trail SoC Integrated Graphics
