JPWR1 DC-IN power connector Power Jack mini din 4P
MPCIE1 Mini PCI Express connector
JCASH1 Cash Drawer
JLAN1/2 RJ-45 Ethernet connector 1/2
JVGA1 VGA connector 8 x 2 wafer, pitch 2.00mm
JLED1 LED connector 5 x 2 wafer, pitch 2.00mm
JSPK1/2 Speaker connector 1/2 2 x 1 wafer, pitch 2.00 mm
JLVDS1 LVDS connector 2 x 20 wafer, pitch 1.25 mm
SIM1 SIM Card Slot SDCARD_9H, Push/Push Type
JMIC1 Line In, MIC connector 4 x 1 wafer, pitch 2.00mm
JBKLT1 LCD inverter connector 5 x 1 wafer, pitch 2.00mm
JMSD1 Micro SD Card Slot
JUART1 Debug UART connector
Debug message output for
users development phase only
JHDMI1 HDMI connector
JI2C1 I2C device connector 5 x 1 header, pitch 2.00mm
