ACP-IMX6POS User’s Manual
10 ACP-IMX6POS User’s Manual
Audio
I2S Codec Wolfson WM8962
Audio Port 2Pin Wafer Box P=2.0m x 2 (Speaker out R & L ) (Driver per channel max 2W)
Mic 4Pin Wafer Box P=2.0m x 1(Microphone)
Ethernet
LAN Chip
1
st
LAN => from i.MX6 MAC, PHY is Micrel KSZ9031RNX
2
nd
LAN => Intel 82574L by PCIe interface
Ethernet Interface 2 x RJ45 connectors for Dual G LAN
Internal I/O
Connectors
RTC Battery CR2032 Battery with cable
Power ON BOX header for Power Button (The first time auto power on)
Reset BOX header for Reset Button
Audio 2P BOX header x 2 (Speaker out R & L ) (Driver per channel max 2W)
Rear I/O Connectors
USB USB Type A Double Deck x 1
LAN RJ45 connector with indicate LED x 2
HDMI HDMI connector x 1 (Vertical type)
Mini-USB Mini-USB connector x 1
RJ11 RJ11 connector x 1 for cash drawer
COM Port DB9 male connector x 2
DC Jack Wide range DC 12V to 24V power input by DC Jack connector
Mechanical &
Environmental
Power Requirement TBD
Power Type DC 12-24V power input
Operating Temp. 0~60 degree C
Storage Temp. -40~85 degree C
Operating
Humidity
12hrs operation dwell time at 40℃/80% Relative Humidity, Non-condensing
Size (L
x W)
175 x 110mm
Weight TBD
Note: Specifications are subject to change without notice.
