Connectors
Label Function Note
BAT Battery connector 2 x 1 wafer, pitch 1.25mm
CFCARD Compact Flash card connector
COM1 Serial Port 1 connector D-sub 9 pin, male
CPU_FAN CPU fan connector 3 x 1 wafer, pitch 2.54mm
DIMM 204-pin DDR3 SODIMM socket
JAUDIO Audio connector 6 x 2 header, pitch 2.0mm
JBKL1 LCD Inverter connector 5 x 1 wafer, pitch 2.0mm
JBKL2 LCD Inverter connector 5 x 1 wafer, pitch 2.0mm
JCOM2 Serial Port 2 connector 5 x 2 header, pitch 2.0mm
JCOM3 Serial Port 3 connector 5 x 2 header, pitch 2.0mm
JCOM4 Serial Port 4 connector 5 x 2 header, pitch 2.0mm
JCOM5 Serial Port 5 connector 5 x 2 header, pitch 2.0mm
JCOM6 Serial Port 6 connector 5 x 2 header, pitch 2.0mm
JDIO General purpose I/O connector 10 x 2 header, pitch 2.0mm
JHS Handset speaker Mode selector 3 x 2 header, pitch 2.0mm
JLED LED indicator connector 7 x 2 header, pitch 2.0mm
JLVDS1 LVDS Connector DIN 40-pin wafer, pitch 1.25mm
JLVDS2 LVDS Connector DIN 40-pin wafer, pitch 1.25mm
JTOUCH Touch panel connector 5 x 1 header, pitch 2.54mm
JUSB1 USB connector 4&5 5 x 2 header, pitch 2.0mm
JUSB2 USB connector 2&3 5 x 2 header, pitch 2.0mm
JUSB4 USB connector 9 6 x 1 header, pitch 2.0mm
JKEY OSD for front panel key 8 x 1 wafer, pitch 2.0mm
LAN1 RJ-45 Ethernet 1
KBMS Keyboard & Mouse (LAN2-Optional)
LED LED indicator connector
LINOUT Audio line-out connector
MPCIE1 Mini-PCI connector 1
MPCIE2 Mini-PCI connector 2
PRINT Optional LPT Connector
PWR1 Power connector
PWR2 Power connector 2 x 2 wafer, pitch 2.0mm
RSBTN Reset button
S_PWR1 Serial ATA power connector 2 x 1 wafer, pitch 2.0mm
SATA1 Serial ATA connector 1
SATA2 Serial ATA connector 2
USB1 USB connector 0&1
VGA VGA connector D-sub 15-pin, female
