ECM-LX800W Series
14 ECM-LX800W Series User ‘s Manual
1.5 System Specifications
System
CPU Onboard AMD Geode [email protected] 500 MHz
BIOS Award 4Mbit Flash BIOS
System Chipset AMD Geode CS5536
I/O Chip Winbond W83627DHG-PT
PCI to ISA Bridge Chip ITE IT8888G
System Memory One 200-pin SODIMM socket supports up to 1GB DDR 333/400 SDRAM
SSD 1 x CF Type I/II
Watchdog Timer Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
H/W Status
Monitor
Monitoring system temperature, voltage, and cooling fan status. Auto
trotting control when CPU overheats
Expansion 1 x PC/104
I/O
MIO
1 x EIDE (Ultra DMA 100, 44pin pitch 2.0mm)
4 x Serial (COM1 with DB-9 & COM2-4 with 5 x 2, pitch 2.0 pin header.
COM2 can be set as RS-232/422/485)
1 x K/B & Mouse
1 x LPT (Supports SPP, ECP, and EPP modes, 26pin, 2.0mm)
2 x Serial ATA ports (7-pin with +5V power for SATADOM),
2 x SATA power connector (+5V)
USB 2 x USB 2.0 ports (5 x 2, pitch 2.0mm pin header)
IrDA 115k bps 1.0 compliant
DIO 8-bit GPIO
Internal I/O Connector Front Panel LED Connector (for system use)
Display
Chipset
AMD Geode™ LX 800 Integrated
Display Memory 8~254 MB frame buffer using system memory
Resolution
CRT mode: 1920 x 1440 @ 32 bpp (85 Hz)
TFT: 1600 x 1200 @ 16 bpp (60 Hz)
Multiple Display CRT + LVDS
VGA/LCD Interface PCI Bus VGA/LCD interface, Support 18/24-bit TFT panel
LVDS Interface
Chipset: NS DS90C363A (18-bit); (NS DS90C385A(24-bit)) [Co-lay]
Support 18-bit LVDS Panel (24-bit is optional)
