ECM-CDV User ’s Manual
ECM-CDV User ’s Manual 47
3.6.2.10.2 Serial Port 1 Configuration
Item Option Description
Serial Port
Enabled,
Disabled
Use the Serial port option to
enable or disable the serial port.
Change Settings
Auto
IO=2F8h; IRQ=3,
IO=3F8h; IRQ=3,4,5,6,7,10,11,12
IO=2F8h; IRQ=3,4,5,6,7,10,11,12
IO=3E8h; IRQ=3,4,5,6,7,10,11,12
IO=2E8h; IRQ=3,4,5,6,7,10,11,12
Use the change Settings option to
change the serial port IO port
address and interrupt address.
UART 232 422 485
UART 232,
UART 422,
UART 485
Change the Serial Port mode.
Select or
mode
