ECM-DX2 Quick Installation Guide
8 ECM-DX2 Quick Installation Guide
SPWR1 SATA Power connector 2 x 1 wafer, pitch 2.00 mm
PC-104 PC-104 connector 20 x 2 header, pitch 2.54mm
PC-104 PC-104 connector 32 x 2 header, pitch 2.54mm
JTG1 Reserved for Debug 3 x 2 header, pitch 2.00 mm
AUD1 Audio connector 6 x 2 header, pitch 2.00 mm
BKL1 LCD inverter connector 5 x 1 wafer, pitch 2.00 mm
COM1 Serial port 1 connector D-sub 9-pin, male
COM2/3/4 Serial port 2/3/4 connector 5 x 2 header, pitch 2.00 mm
DIO1 General purpose I/O connector 6 x 2 header, pitch 2.00 mm
TTL1 TFT panel connector 20 x 2 wafer, pitch 1.25 mm
VR1
LCD backlight brightness adjustment
connector
3 x 1 header, pitch 2.54 mm
LVDS1 LVDS connector 10 x 2 wafer, pitch 1.25 mm
BPWM1 LCD PWM Mode Selector 2 x 1 header, pitch 2.00mm
RS1 Reset button
USB1/2 On-board pin header for USB2.0 5 x 2 header, pitch 2.00 mm
LAN1/2 RJ-45 Ethernet connector
D16 LED connector
PWRSB1 5VSB connector in ATX 3 x 1 wafer, pitch 2.54 mm
PWR1 Power connector 2 x 2 wafer, pitch 4.20 mm
KBMS1 PS/2 keyboard & mouse connector
SATA1 Serial ATA connector 1
CN1 VGA connector D-sub 15-pin, female
MPCIE1 Mini-PCI connector
CF1 CF card slot
Limitation:
1. Attach a modem to COM2/COM3 when the modem power is off would result in OS to be freezed in
Windows XP logo.
Power on the modem would continue to complete Windows booting process.
2. Text in in DOS might be out of screen at random.
3. Resolution needs to be set correctly in case of screen ambiguity in Windows 2000 after the graphic driver
installation.
4. Link LED keeps the same green color in both 10M/100Mbps for DM&P Vortex86DX LAN chip.
5. HDD LED is working functionally when reading/writing CF cards, but fails in SATA devices.
