ECM-DX2 Quick Installation Guide

18 ECM-DX2 Quick Installation Guide

2.3.17 On-board pin header for USB2.0 (USB1)

Signal

PIN PIN

Signal

+5V

1

2

GND

USB0N

3

4

GND

USB0P

5

6

USB1P

GND

7

8

USB1N

GND

9

10

+5V

2.3.18 On-board pin header for USB2.0 (USB2)

Signal

PIN PIN

Signal

+5V

1

2

GND

USB2N

3

4

GND

USB2P

5

6

USB3P

GND

7

8

USB3N

GND

9

10

+5V
