DX402/DX502/DX602 User’s Guide & Operating Manual
4.7.3 Antenna cables for the Wireless Digital Link (WDL)
The WDL antenna cable is a MCX to BNC 50 OHM cable.
4.7.4 Splitters
When a set of four antennas feeds more than one receiver, it is
convenient to split the signal from each antenna to all receivers at the
same location.
Ordering information:
Splitter type
DX402/DX502
(F-F)
DX602
(SMA-SMA)
1 to 2 (two DX..2)
SP2F
SP2S
1 to 3 (three DX..2)
SP3F
SP3S
1 to 4 (four DX..2)
SP4F
SP3S
1 to 8 (eight DX..2)
SP8F
SP8S
4.7.5 Splitter to receiver cables.
The use of splitters requires jumper cables from every splitter output
to every receiver antenna input. Ordering information for a four
receiver system:
Number of DX..2
Receivers
Number
of cables
DX402/DX502
DX602
2
8
CBLFF-2
CBLSS-2
3
12
CBLFF-2
CBLSS-2
4
16
CBLFF-2
CBLSS-2
4.7.6 Wireless Digital Link (WDL) combiner cables.
A RF signal combiner feeds one DWL antenna and antenna cable
from is used to drive the DWL signals from more than one DX..2
receiver to a single DWL antenna and antenna cable.
