www.austin-hughes.com UM-PPS-02-S-Q214V1 P.5
Step 1 - Press the & button to display no.9 and press to confi rm
Step 2 - Press the & button to PDU ID and press to confi rm
Step 3 - In display 9.1, Press the & button to select PDU level no. & press to confi rm
Step 4 - Press to exit
< 1.3 > W meter setting
W meter allows the user to do some settings below :
Buzzer :
W meter allows the user to set the meter buzzer ON / OFF by meter’s 4 buttons
Screen OFF :
All PDUs are shipped with the metter LCD in always ON status.
W meter allows the user to turn off the meter LCD by time setting ( 1 - 60 mins, 0 = always ON )
When the meter is in OFF status, the user can press any button to make it ON.
Outlet ON :
This is for WS kWh Switched / WSi outlet kWh Switched PDU models only. All Switched PDUs
are shipped in outlet ON status.
PDU level setting :
