Page 3
iQ Series,
Auto User’s Manual
Dukane Manual Part No. 403-573-02
AC Power Requirements
Operating
Frequency
Generator
Model Number
Overload
Power Ratings
(Watts)
Input AC Power Requirements
Nominal AC Volt
@ Maximum RMS Current
North America/
Japan AC Outlet
Rating
20kHz 20AT060-1X-XX 600 100-120V 50/60 Hz @ 15 Amps
15 Amps
20kHz 20AT060-2X-XX 600 200-240V 50/60 Hz @ 6.3 Amps
30kHz 30AT060-1X-XX 600 100-120V 50/60 Hz @ 15 Amps
30kHz 30AT060-2X-XX 600 200-240V 50/60 Hz @ 6.3 Amps
40kHz 40AT060-1X-XX 600 100-120V 50/60 Hz @ 15 Amps
40kHz 40AT060-2X-XX 600 200-240V 50/60 Hz @ 6.3 Amps
Table 5-I AC Power Requirements
NOTE
Standard iQ Auto model = XXAT060-XN
iQ Auto with MPC model = XXAT060-XN-M0
