Page iii Dukane Manual Part No. 403-573-02
Revision History
Revision Revision
Number Summary Date
- 00 Original release. 10/09/2007
- 01 20kHz and 30kHz models added. 08/27/2009
System I/O Connector signals modified.
Amplitude control added.
- 02 I/O Connector Pin 9 signal scale revised. 12/15/2010
Miscellaneous spelling errors corrected.
Fig 5-1 and 5-2 dimensions edited.
Fault conditions modified:
Negative Peak Overload eliminated;
Positive Peak Overload changed to Peak Overload;
Frequency Lock Lost changed to Frequency Overload.
Copyright page modified: Specifications subject to change statement added,
and Patent 7,819,158 B2 added.
Updated Dukane ISO certification statement to 2008.
How to Lift Safely information added to Section 2, Health and Safety.
International Protection Rating added to Section 5, Specifications.
