SET TOP BOX SPECIFICATIONS & TROUBLESHOOTING
Set Top Box Specifications
Input impedance 75 Ohm
Video Profile level MPEG 2 MP @ ML / MPEG 4 – Part 10 / VC 1
Video Output System PAL
Video Output Terminal Composite Video Output, HDMI Output
Video Output Level 1 V
p
-
p
(75 Ohm )
Audio Decoding MPEG 1 Level II / MPEG 2 AAC / MPEG 4 AAC / MPEG 4
AAC-HE / MPEG 4 AAC-HE V 2 / WMA- 9 / 9 Pro / AC 3
Audio Sampling Frequency 32 / 44.1 / 48 KHz
Audio Frequency Response 20 Hz – 20 KHz
Audio Output Level Adjustable
Audio Output Terminal Analogue Audio 2 Ch (Left & Right), SPDIF
Power Supply Adapter Input: 100-240 V~, 50 / 60 Hz, 2 A~; Output: 12 Vdc, 4 Adc
Operating Temperature 5 - 45 ˚C
Weight 1.8 Kg
Trouble Shooting
Problem Possible Causes Solution
Set top box freezes
(not responding)
Internal CPU and or memory
may have corrupted Try unplugging the AC mains
or disconnect the power supply
adapter at the back of the set top box.
This will reset the set top box
and re-starts the boot up sequence.
Event is PG blocked /
Channel blocked
Parental control may have been
set. Key in PG PIN. The default pin is 1234.
Can’t play video or music
from external USB device USB device may not have been
properly inserted.
Video or Music format may not
be supported by the set top box
Try re-plugging the USB device into
the socket and check if external USB
is detected via Menu Settings
Device info USB device.
This set top box supports the most
common music and video file formats.
However, there may be some formats
that are not supported.
