Altech UEC DT 7101 User Manual
Altech UEC Video

Altech UEC
A.C.N. 095 001 022
www.uec.com.au
27 Sirius Road
Lane Cove West NSW 2066
AUSTRALIA
Tel: +61 2 9425 5777
Fax: +61 2 9425 5799
[email protected]
*Specifications subject to change without notice
Audio Decoding
•
- MPEG-1/2 layer 1/11, AC3/HE-AAC
- Frequency Response: 20Hz/20KHz
- Analogue Audio Outputs: Stereo L&R
- Digital Audio Output: HDMI/SPDIF (coaxial)
Video Decoding
•
- AVC,MPEG 2/4, H264 MP@ML/HL
- Display Aspect Ratio: 16:9/4:3/4:3 Letterbox
- PAL Video Output support
- HD Digital Output: HDMI - 576i, 576p, 720p, 1080i
- HD Analogue Output: YPbPr - 576p, 720p, 1080i
- SD Video Output YPbPr – 576i
- SD Video Output: TV SCART / VCR loop through
Outputs
•
- HDMI
- YPbPr&audio L&R
- SPDIF (coaxial)
- TV SCART output / VCR SCART Input/Output
Power
•
- Power: AC 240V~50Hz
- Max < 15W
Dimensions: 280(W)x235(D)x37(H)
Key Features
•
- Australian Freeview DVB-T Compliant
- AS4933 Australian DVB-T standard
- MPEG 2/4, H.264, for high definition video output
(support 576p,720p, 1080i)
- Easy-to-use Graphical User Interface
System
•
- Main CPU: STi7101, 32-bit superscalar RISC (266
MHz).
- Memory: 256Mbits x 4
- Flash Memory: 64Mbits
- 8 day EPG Picture in graphics
- Parental lock
- Last Channel memory, Favourite channel
- S/W upgrade over the air and via USB port
- Front panel display and navigation keys for menu,
ok, channel up/down, volume up/down, standby
Terrestrial Input Signal
•
- Input Frequency: VHF/UHF, 45MHz to 230MHz,
470 MHz to 862MHz
- Transmission System: DVB-T COFDM
- Channel Bandwidth: 7MHz
- Input Signal -80dBm to -20dBm
- Antenna Input: 75Ohm Female IEC-Connector
- OFDM Spectrum Mode: 2K/8K, Hierarchical
- Modulation Modes: QPSK, 16QAM, 64QAM
- Guard Interval Modes:1/32, 1/16, 1/8, 1/4 Active
Symbol Duration.
- FEC Modes; Rate 1/2, 2/3, 3/4, 5/6, 7/8
