ADVANCED CONTROL TECHNOLOGIES, INC.
Indianapolis, Indiana 46278 RB104 Installation Instructions
P/D 012408
Supply Voltage: 120/208 VAC, +/-10%, 50 or 60 Hz
Power Consumption: Less than 4.5W
Powerline Carrier Signal Input: X10 Powerline Carrier, sensitive to 50 millivolts
Signal Output (Status):
X10 Powerline Carrier, 6V peak to peak @ 5 ohms
Maximum switching capacity: Resistive: 30A, 277 VAC - N.C. or N.O. contacts
Motor: 1 H.P., 120 VAC or 1.5 H.P. 200 -600 VAC - N.C. or N.O. contacts
Ballast: 120 VAC, 10A - N.C. contact or 30A - N.O. /277 VAC, 10A - N.C. contact or 20A - N.O.
Tungsten 2A, 120 VAC - N.C. contact or 10A, 120 VAC - N.O. contact
Resistive DC: 30A, 28 VDC, - N.C. or N. O. contacts
Fuses (control circuit only): Two (2) 5 x 20mm time lag fuses rated 0.5A, 250V, user replaceable (Littlefuse 239,500 or Buss GDC-500mA).
Setting the time-out feature
Default state
First place the RB104 in run mode , then press the configuration button 3 times rapidly. After
releasing the button after the third press, the Status LED will stay on. This indicates RB104
is in time-out configuration mode.
Transmit the desired default state (Standard Code ON or OFF) twice in succession
(separated by six zero crossings) Note: the transmitter must be set to the same letter code
as the configured address.
The Status LED will blink 8 times if configured to default to OFF.
The Status LED will blink 7 times if configured to default to ON.
Default Time-out (Optional Feature)
After the default state is configured, the time-out time can be configured.
Transmit the desired time-out by transmitting a number code to the RB104 twice.
Number code 1 for example, will configure the unit to default to its default state after 1 hour.
Number code 2, will configure the unit to default to default to its default state after two hours.
And so on. The unit can be configured to default from 1 to 16 hours.
When the time-out period has been accepted the Status LED will flash 1 time and then
resume to being continuously on.
To exit time-out configuration mode, the configuration button can be pressed. The Status
LED will resume blinking. The RB104 will exit time-out configuration mode and reenter run
mode after one minute of no activity.
CHECKOUT
1. Test Operation:
Using a controller, transmit appropriate commands to ensure proper operation and
interference filtering. This product is compatible with standard X10 systems.
2. If at any time the STATUS LED flashes off and on quickly without stopping, reset the RB104
by powering the unit down and back up. If the error returns and cannot be cleared through
a reset, the unit could need repair or replacement.
