2 The External Switch is only operational while the ON/OFF/AUTO switch is in the "AUTO”
position.
3. The External Switch is not required for proper operation of the unit - only use if this feature
is desired.
The RB104 features two operating modes: Normal Mode and Configuration Mode. The Normal
Mode is the state in which the device performs its primary function. The Configuration Mode allows
the user to specify the address by which the device may be controlled, and allows the user to enable
“All Lights On, All Units Off, All Lights Off commands” (disabled when address is set), disable “polite
mode” and enable “rude mode”, enable "power-up to last known state", and set the "time out"
feature.
OPERATION
If the RB104 address is configured to a standard code address…
The RB104 will respond to standard code On, Off, and Status Request commands.
The RB104 will respond with standard code Status On or Status Off commands when it
receives the standard code Status Request command.
If the RB104 address is factory configured to an extended code address or configured in the
field (see attached "Extended Code" Addendum for extended code instructions):
The RB104 will respond to standard code On and Off commands addressed to the Letter
code and Unit code of its extended code address.
It will also respond to extended code On, Off, and Status Request commands.
The RB104 will respond with extended code Status On or Status Off commands when it
receives the extended code Status Request command.
CONFIGURING
To set the address:
Press and hold the configuration button for 3 seconds. After 3 seconds, release the button. The
status LED should no longer be blinking and should be on steady. The RB104 can now be
addressed.
Using a transmitter, transmit the desired address twice in succession. The transmissions must
be separated by at least six zero crossings (50mS to 60mS, dependent on line frequency). The
RB104 will blink twice to indicate acceptance of desired address. The unit defaults to polite when
the address is configured.
To disable “polite mode” and enable “rude mode”:
Transmit the configured address twice more in succession (separated by at least six zero
crossings). The Status LED will blink 4 times.
To enable “All Lights On, All Units Off, All Lights Off commands”:
To enable each command, transmit the command twice in succession (separated by at least six
zero crossings). The Status LED will blink 6 times when All Lights On is enabled, 10 times when
All Units Off is enabled, and 8 times when All Lights Off is enabled.
To enable “Power Up to Last Known State”:
After the address has been configured, transmit a Standard Code ON command twice in
succession (separated by at least six zero crossings). The Status LED will blink 5 times to
indicate this feature has been enabled.
To exit configuration mode
To exit configuration mode, the configuration button can be pressed. The Status LED will resume
blinking. The RB104 will exit configuration mode and reenter run mode after one minute of no
activity.
