0693-01

3

RF234 Installation Instructions

P/D 071404

ADVANCED CONTROL TECHNOLOGIES, INC.
Indianapolis, Indiana 46278

Supply Voltage

208/240 VAC, +/-10%, 50 or 60 Hz

Power Consumption

Less than 4.5W

Signal Input

120 KHz +/- 4 KHz, sensitive to 25 millivolts

Signal Output (Status)

5V peak to peak @ 5 ohms

Maximum switching capacity

20 Amps or 5000 VA

Maximum switching voltage

305 VAC

equipment.

TROUBLSHOOTING

If the LED continues to blink repeatedly, recycle power to the unit, and then reprogram the unit. If problem remains
after power-up and reprogramming, return the unit to the distributor where purchased and replace the unit.

WARRANTY

For warranty and general product information visit our web site at
www.act-solutions.com

ABOUT CERTIFICATION

This product has been thoroughly tested by the ETL SEMKO division of Intertek, a
nationally recognized testing laboratory. This product was found to be in compliance with
safety standards ANSI/UL STD 244A and CAN/CSA C22.2 No. 177.
