System Description 5
STC-15W04
2 System Description
2.1 Specifications
Display
Display Size 15.6”
Resolution 1366x768 pixels
Brightness 300 nits (w/o touchscreen)
Contrast Ratio 500:1 typical
Touchscreen
Projected capacitive full-flat multi-touch display
(glass)
System Components
Processor Intel® Atom™ Processor D2550
Chipset Intel® NM10 Express Chipset
Memory 2GB DDR3 SO-DIMM (max. 4GB)
Storage Industrial CFast card (default 8GB)
I/O
2x USB 2.0 ports
2x GbE ports (2x Realtek 8111E)
1x RS-485 port (isolated)
Operating System Windows 7 Professional 32-bit (pre-installed)
Mechanical
Construction Anodized aluminum front bezel and steel chassis
Weight 5.5 kg (12.1 lb)
Dimensions (WxHxD) 407.3 x 262.3 x 67.2 mm
Mounting Panel mount (cut-out: 380 x 235 mm)
Environmental
Temperature
Operating: 0°C to 50°C
Storage: -20°C to 60°C
Relative Humidity 95% non-condensing
Vibration EN 60068-2-6 (1G, 10Hz~500Hz
Shock IEC 60068-2-27 (15G, 11ms)
Ingress Rating IP65 front panel, IP20 rear enclosure
Certifications &
Compliance
CE (IEC 61010-2-201)
UL 508 + CSA-C22.2 No. 142
cUL and UL C1D2 (UL 1604)
IEC Ex XX T4 (IEC 60079-15, IEC 60079-0)
EMC
CE (EN 61000-6-2, EN 61000-6-4)
FCC (Part 15 Subpart B)
