20 Getting Started
SATA2 Connectors (SATA_4/SATA_5)
Enable Serial ATA2 data input at up to 3.0 Gb/s.
SATA3 Connectors (SATA_0/SATA_1)
Enable Serial ATA3 data input at up to 6.0 Gb/s.
USB 2.0 Headers (9-pin USB6_7/USB8_9))
In addition to the four on the I/O panel, two
USB 2.0 headers on the board each
support two USB 2.0 ports.
SA
T
A_5
SA
T
A_4
SA
T
A_1
SA
T
A_0
NC
GND
GND
+
-
PWR
+
-
PWR
1
6
1
