34 • Power Supply Unit
Input Characteristics
• Voltage: 90 – 240 VAC Full Range
• Frequency : 47 ~ 63 HZ
• Input Current: 8.0 A ( RMS ) FOR 115 VAC
4.0 A ( RMS ) FOR 230 VAC
• Inrush Current: 65A MAX. FOR 115 VAC
125A MAX. FOR 230 VAC
Output Characteristics
Output Current(A) Regulation Output
Output
Voltage
MIN. MAX. PEAK LOAD LINE
Ripple&
Noise
Max[P-P]
5V 3 35 – ± 5% ± 1% 50mV
12V 2 30 – +7 – -5% ± 1% 120mV
-5V 0 0.5 – ± 5% ± 1% 150mV
-12V 0 0.8 – ± 5% ± 1% 150mV
3.3V 1 28 – ± 5% ± 1% 50mV
+5VSB 0.1 2 – ± 5% ± 1% 50mV
Note: The output current of 5V & 3.3V must not exceed 45A.
