Power Supply Unit • 25
5 Power Supply Unit
The cPCIS-2501 is equipped with ADLINK’s cPS-H325/AC CompactPCI power
module.
5.1 CompactPCI: cPS-H325/AC
Features
• 250W 3U X 8HP Eurocard package
• Meets IEC1000-3-2 harmonic correction
• Internal OR-ing diodes for N+1 redundancy
• Hot-swappable
•
Third-wire current sharing
• EMI meets EN 55022 / FCC CLASS A
• CE marking compliance
• Fully compliant with PICMG
Specifications
• Operating Temperature Range: 0 °C to 50°C
• Storage Temperature: -40 to +85 °C
• Temperature Coefficient: Typ. ±0.02% / °C
• Cooling: >20 CFM moving air required to achieve full rated power
• Dimensions: Eurocard 3U X 8HP X 160mm CompactPCI format
• Efficiency: 78-79% typical
• Switching Frequency: 120K Hz
• Safety: IEC60950 Class I
• Circuit Topology: Forward circuit
• Transient Response: Peak transient less than 100mV and recovers
within 2mS after 25% load-change
