Introduction
• 19
1.7.4 Connector Pin Assignment of C888
DB62 female connector pin assignment for C888.
DB62 Pin
No.
Signal Name
DB62 Pin
No.
Signal Name
DB62 Pin
No.
Signal Name
1 TXD1(OUT) 22 TXD2(OUT) 43 GND
2 RXD1(IN) 23 RXD2(IN) 44 GND
3 RTS1(OUT) 24 RTS2(OUT) 45 GND
4 CTS1(IN) 25 CTS2(IN) 46 TXD4(OUT)
5 DSR1(IN) 26 DSR2(IN) 47 RXD4(IN)
6 DTR1(OUT) 27 DTR2(OUT) 48 RTS4(OUT)
7 DCD1(IN) 28 DCD2(IN) 49 CTS4(IN)
8 TXD3(OUT) 29 TXD7(OUT) 50 DSR4(IN)
9 RXD3(IN) 30 RXD7(IN) 51 DTR4(OUT)
10 RTS3(OUT) 31 RTS7(OUT) 52 DCD4(IN)
11 CTS3(IN) 32 CTS7(IN) 53 TXD8(OUT)
12 DSR3(IN) 33 DSR7(IN) 54 RXD8(IN)
13 DTR3(OUT) 34 DTR7(OUT) 55 RTS8(OUT)
14 DCD3(IN) 35 DCD7(IN) 56 CTS8(IN)
15 TXD5(OUT) 36 TXD6(OUT) 57 DSR8(IN)
16 RXD5(IN) 37 RXD6(IN) 58 DTR8(OUT)
17 RTS5(OUT) 38 RTS6(OUT) 59 DCD8(IN)
18 CTS(IN) 39 CTS6(IN) 60 GND
19 DSR5(IN) 40 DSR6(IN) 61 GND
20 DTR5(OUT) 41 DTR6(OUT) 62 GND
21 DCD5(IN) 42 DCD6(IN) -- --
