4
• Introduction
1.4 C588 Specifications
♦ PCI Spec.2.1compliant
♦ Serial communication controller:
• 16C550A
compatible
• 1.8432 - 7.3728MHz
♦ System IO mapping:
• Assigned by PCI BIOS
• Shared
IRQ
♦ Flow
control:
• Xon/Xoff
control
• RTS/CTS
control
♦ Port
Capability:
• 8 independent RS-232C compatible ports
• Optional external C584XB box for extending to 8 isolated
RS-232/422/485 ports
• Max. port per system: 16 Ports (2 cards)
♦ Baud rate: Each port can be configured to 50 - 115,200bps
♦ Operation System Compatibility: Windows 98/2000/XP/NT, Linux
♦ Connector: DB62 female connector
♦ Cable: External cable with 8 standard DB9/25 male connector
♦ Operating temperature: 0 to 55 °C
♦ Storage temperature: -10 to 70 °C
♦ Humidity : 10% to 95%, non-condensing
♦ Power consumption: +5V @ 1400mA typical
