Introduction • 3
1.3 Specifications
I/O channels 24-bit for PCI-7224
48-bit for PCI-7248
96-bit for PCI-7296
48-bit for cPCI-7248 and cPCI-7249R
Digital Input Signal Logic High Voltage:2.0 V to 5.25V
Logic Low Voltage: 0.0 V to 0.80V
Logic High Current: 20.0 uA
Logic Low Current: -0.2 mA
Digital Output Signal Logic High Voltage: Minimum 2.4 V
Logic Low Voltage: Maximum 0.5V
Logic High Current: -15.0 mA
Logic Low Current: 24.0 mA
Operating Temperature 0 °C ~ 60°C
Storage Temperature -20°C ~ 80°C
Humidity 5% ~ 95% non-condensing
I/O Connectors 50-pin male ribbon cable connectors for PCI-
7224/7248/7296 or
100-pin SCSI-type connectors for cPCI-7248
Bus PCI bus for PCI-7224/7248/7296
3U 32-bit CompactPCI Bus for cPCI-7248
Power Consumption
(without external devices)
PCI-7224:
330mA @5V
DC
(Typical)
350mA @5V
DC
(Maximum)
PCI-7248:
500mA @5V
DC
(Typical)
540mA @5V
DC
(Maximum)
PCI-7296:
860mA @5V
DC
(Typical)
940mA @5V
DC
(Maximum)
cPCI-7248:
470mA @5V
DC
(Typical)
560mA @5V
DC
(Maximum)
cPCI-7249R:
700mA @5VDC ( Typical)
Transfer Rate 500 K bytes/sec (Maximum)
PCB Dimension PCI-7224: 148mm x 102mm
PCI-7248: 148mm x 102mm
PCI-7296: 166mm x 102mm
cPCI-7248: 3U CompactPCI form factor
cPCI-7249R: 3U CompactPCI form factor, J2
with Rear I/O option
