28 ● Pin Assignments
Note 2: Please refer the following table for the routing of the PXI_STAR
addressing signals from the trigger slot to peripheral slots.
Physical Slot
Number
PXI_STAR
(P2-D17)
Slot 2
(Star Trigger Slot)
PXI_STAR0
~ PXI_STAR5
Slot 3 PXI_STAR0
Slot 4 PXI_STAR1
Slot 5 PXI_STAR2
Slot 6 PXI_STAR3
Slot 7 PXI_STAR4
Slot 8 PXI_STAR5
B.2.2 Miscellaneous Connectors Pin Assignments
CN3: ATX-like DC Power input connectors
Signal Name Pin # Pin # Signal Name
V2SENSE 1 11 V2 (+3.3V)
V2 (+3.3V) 2 12 V4 (-12V)
GND 3 13 GND
V1 (+5V) 4 14 INH#
GND 5 15 GND
V1 (+5V) 6 16 SRTN
GND 7 17 GND
FAL#1 8* 18* V3SENSE
DEG#1 9* 19 V1SENSE
V3 (+12V) 10 20 V1 (+5V)
Note 1: Pin #8, #9, and #18 are not standard ATX power definition.
General Purpose screw terminals
Position Signal Name
J4 +3.3V
J6 V(I/O)
J7 +5V
Note that the V(I/O) must be shorted to either +3.3V or +5V. The default factory
setting is to short V(I/O) to +5V.
