Pin Assignments
• 27
General Peripheral Slot (Slot #3~#6) P2 Pin Assignment
Pin Z
A
B
C
D
E
F
22
GND
PXI_BRSVA22 PXI_BRSVB22 PXI_BRSVC22 PXI_BRSVD22 PXI_BRSVE22 GND
21
GND
PXI_LBR0 GND PXI_LBR1
PXI_LBR2
PXI_LBR3
GND
20
GND
PXI_LBR4
PXI_LBR5
PXI_LBL0 GND PXI_LBL1
GND
19
GND
PXI_LBL2 GND PXI_LBL3
PXI_LBL4
PXI_LBL5
GND
18
GND
PXI_TRIG3
PXI_TRIG4
PXI_TRIG5 GND PXI_TRIG6
GND
17
GND
PXI_TRIG2 GND
N/C PXI_STAR
(2)
PXI_CLK10
GND
16
GND
PXI_TRIG1
PXI_TRIG0 N/C
GND PXI_TRIG7
GND
15
GND
PXI_BRSVA15
GND N/C
PXI_LBL6
PXI_LBR6
GND
14
GND AD[35]
AD[34]
AD[33] GND AD[32] GND
13
GND AD[38]
GND
V(I/O) AD[37] AD[36]
GND
12
GND AD[42]
AD[41]
AD[40] GND AD[39] GND
11
GND AD[45]
GND
V(I/O) AD[44] AD[43]
GND
10
GND AD[49]
AD[48]
AD[47] GND AD[46] GND
9
GND AD[52]
GND
V(I/O) AD[51] AD[50]
GND
8
GND AD[56]
AD[55]
AD[54] GND AD[53] GND
7
GND AD[59]
GND
V(I/O) AD[58] AD[57]
GND
6
GND AD[63]
AD[62]
AD[61] GND AD[60] GND
5
GND C/BE[5]#
GND
V(I/O)
C/BE[4]#
PAR64 GND
4
GND V(I/O)
PXI_BRSVB4
C/BE[7]# GND C/BE[6]#
GND
3
GND
PXI_LBR7 GND PXI_LBR8
PXI_LBR9
PXI_LBR10 GND
2
GND
PXI_LBR11
PXI_LBR12
N/C (SYS#)
PXI_LBL7
PXI_LBL8 GND
1
GND
PXI_LBL9 GND PXI_LBL10
PXI_LBL11
PXI_LBL12 GND
Pin Z
A
B
C
D
E
F
Note 1: Please refer the following table for the routing of the Bus Mastering
(REQ/GNT), IDSEL, PCI CLK, and Interrupt signals.
IDSEL
REQ#
/GNT#
PCI
CLK
PXI P1
Pin A3
PXI P1
Pin B3
PXI P1
Pin C3
PXI P1
Pin E3
Slot 1(SYS)
-
-
-
INTA#
INTB# INTC#
INTD#
Slot 2
AD31
0
6
INTD#
INTA#
INTB#
INTC#
Slot 3
AD30
1
5
INTC#
INTD#
INTA#
INTB#
Slot 4
AD29
2
1
INTB#
INTC#
INTD#
INTA#
Slot 5
AD28
3
2
INTA#
INTB#
INTC#
INTD#
Slot 6
AD27
4
3
INTD#
INTA#
INTB#
INTC#
Slot 7
AD26
5
4
INTC#
INTD#
INTA#
INTB#
Slot 8
AD25
6
0
INTB#
INTC#
INTB#
INTA#
